IPAN70R600P7SXKSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 700V 8.5A TO220
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPAN70R600P7SXKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 1,108
Can ship immediately
Pricing:
- 1$1.03
- 500$0.61836
Quote It
Technical Details
- Series:CoolMOS™ P7
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):700 V
- Current - Continuous Drain (Id) @ 25°C:8.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:600mOhm @ 1.8A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 90µA
- Gate Charge (Qg) (Max) @ Vgs:10.5 nC @ 10 V
- Vgs (Max):±16V
- Input Capacitance (Ciss) (Max) @ Vds:364 pF @ 400 V
- FET Feature:-
- Power Dissipation (Max):24.9W (Tc)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO220 Full Pack
- Package / Case:TO-220-3 Full Pack
