CSD19506KTTT

Technical Details

• Series:NexFET™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):80 V
• Current - Continuous Drain (Id) @ 25°C:200A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:2.3mOhm @ 100A, 10V
• Vgs(th) (Max) @ Id:3.2V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:156 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:12200 pF @ 40 V
• FET Feature:-
• Power Dissipation (Max):375W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:DDPAK/TO-263-3
• Package / Case:TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
