MSC060SMA070B
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSICFET N-CH 700V 39A TO247-3
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 311
Can ship immediately
Pricing:
- 1$8.41
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:SiCFET (Silicon Carbide)
- Drain to Source Voltage (Vdss):700 V
- Current - Continuous Drain (Id) @ 25°C:39A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):20V
- Rds On (Max) @ Id, Vgs:75mOhm @ 20A, 20V
- Vgs(th) (Max) @ Id:2.4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:56 nC @ 20 V
- Vgs (Max):+23V, -10V
- Input Capacitance (Ciss) (Max) @ Vds:1175 pF @ 700 V
- FET Feature:-
- Power Dissipation (Max):143W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-247-3
- Package / Case:TO-247-3
