APT40M35JVR

Technical Details

• Series:POWER MOS V®
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):400 V
• Current - Continuous Drain (Id) @ 25°C:93A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:35mOhm @ 46.5A, 10V
• Vgs(th) (Max) @ Id:4V @ 5mA

• Gate Charge (Qg) (Max) @ Vgs:1065 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:20160 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):700W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Chassis Mount
• Supplier Device Package:SOT-227 (ISOTOP®)
• Package / Case:SOT-227-4, miniBLOC
