IRF620STRLPBF
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 200V 5.2A D2PAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRF620STRLPBF Datasheet
-
ECAD Model
- Share
In Stock: 280
Can ship immediately
Pricing:
- 1$2.14
- 800$1.18982
- 1,600$1.09193
- 2,400$1.01662
- 5,600$0.97897
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):200 V
- Current - Continuous Drain (Id) @ 25°C:5.2A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:800mOhm @ 3.1A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:14 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:260 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):3W (Ta), 50W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:D2PAK
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
