IPD30N03S2L20ATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 30A TO252-31
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPD30N03S2L20ATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 801
Can ship immediately
Pricing:
- 1$0.92
- 2,500$0.37052
- 5,000$0.34497
- 12,500$0.33219
- 25,000$0.32522
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:30A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:20mOhm @ 18A, 10V
- Vgs(th) (Max) @ Id:2V @ 23µA
- Gate Charge (Qg) (Max) @ Vgs:19 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:530 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):60W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TO252-3-11
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
