IPB80N03S4L03ATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 80A TO263-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPB80N03S4L03ATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 693
Can ship immediately
Pricing:
- 1$1.61
- 1,000$0.76056
- 2,000$0.70985
- 5,000$0.67436
- 10,000$0.64901
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:80A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:3.3mOhm @ 80A, 10V
- Vgs(th) (Max) @ Id:2.2V @ 45µA
- Gate Charge (Qg) (Max) @ Vgs:75 nC @ 10 V
- Vgs (Max):±16V
- Input Capacitance (Ciss) (Max) @ Vds:5100 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):94W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TO263-3-2
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
