STH3N150-2

Technical Details

• Series:PowerMESH™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):1500 V
• Current - Continuous Drain (Id) @ 25°C:2.5A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:9Ohm @ 1.3A, 10V
• Vgs(th) (Max) @ Id:5V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:29.3 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:939 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):140W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:H²PAK
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab) Variant
