FDP3632
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 100V 12A/80A TO220-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDP3632 Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$3.43
- 10$3.06913
- 100$2.53409
- 800$1.88031
- 1,600$1.76143
Quote It
Technical Details
- Series:PowerTrench®
- Package:Tube
- Part Status:Not For New Designs
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:12A (Ta), 80A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):6V, 10V
- Rds On (Max) @ Id, Vgs:9mOhm @ 80A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:110 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:6000 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):310W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220-3
- Package / Case:TO-220-3
