IXTH1N200P3HV
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 2000V 1A TO247HV
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTH1N200P3HV Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
- 1$7.29
- 30$5.97328
- 120$5.39034
- 510$4.51625
- 1,020$4.07918
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):2000 V
- Current - Continuous Drain (Id) @ 25°C:1A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:40Ohm @ 500mA, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:23.5 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:646 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):125W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-247HV
- Package / Case:TO-247-3 Variant
