IPA60R520CPXKSA1
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 6.8A TO220-FP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPA60R520CPXKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$1.19995
Quote It
Technical Details
- Series:CoolMOS™
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:6.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:520mOhm @ 3.8A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:31 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:630 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):30W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO220-FP
- Package / Case:TO-220-3 Full Pack
