SPA11N60C3XKSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 11A TO220-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SPA11N60C3XKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$3.07
- 500$2.082
Quote It
Technical Details
- Series:CoolMOS™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:11A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:380mOhm @ 7A, 10V
- Vgs(th) (Max) @ Id:3.9V @ 500µA
- Gate Charge (Qg) (Max) @ Vgs:60 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1200 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):33W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO220-3-31 Full Pack
- Package / Case:TO-220-3 Full Pack
