ZVP2110ASTZ
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 100V 230MA E-LINE
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet ZVP2110ASTZ Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$0.37538
- 2,000$0.37538
Quote It
Technical Details
- Series:-
- Package:Tape & Box (TB)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:230mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:8Ohm @ 375mA, 10V
- Vgs(th) (Max) @ Id:3.5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:-
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:100 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):700mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:E-Line (TO-92 compatible)
- Package / Case:E-Line-3
