SIB417EDK-T1-GE3

Technical Details

• Series:TrenchFET®
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):8 V
• Current - Continuous Drain (Id) @ 25°C:9A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):1.2V, 4.5V
• Rds On (Max) @ Id, Vgs:58mOhm @ 5.8A, 4.5V
• Vgs(th) (Max) @ Id:1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:12 nC @ 5 V
• Vgs (Max):±5V
• Input Capacitance (Ciss) (Max) @ Vds:565 pF @ 4 V
• FET Feature:-
• Power Dissipation (Max):2.4W (Ta), 13W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PowerPAK® SC-75-6L Single
• Package / Case:PowerPAK® SC-75-6L
