FQD12N20LTM-F085P
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 200V 9A TO252
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$0.8118
- 2,500$0.8118
Quote It
Technical Details
- Series:QFET®
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):200 V
- Current - Continuous Drain (Id) @ 25°C:9A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):5V, 10V
- Rds On (Max) @ Id, Vgs:280mOhm @ 4.5A, 10V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:21 nC @ 5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1080 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):2.5W (Ta), 55W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-252, (D-Pak)
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
