NVMYS2D2N06CLTWG

Technical Details

• Series:Automotive, AEC-Q101
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:31A (Ta), 185A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:1.9mOhm @ 50A, 10V
• Vgs(th) (Max) @ Id:2V @ 180µA

• Gate Charge (Qg) (Max) @ Vgs:69 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:4850 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):3.9W (Ta), 134W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:LFPAK4 (5x6)
• Package / Case:SOT-1023, 4-LFPAK
