TSM3N80CI C0G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 800V 3A ITO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet TSM3N80CI C0G Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$0.9843
- 10$0.87365
- 100$0.69036
- 500$0.53538
- 1,000$0.42267
- 3,000$0.39449
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):800 V
- Current - Continuous Drain (Id) @ 25°C:3A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:4.2Ohm @ 1.5A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:19 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:696 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):94W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:ITO-220AB
- Package / Case:TO-220-3 Full Pack, Isolated Tab
