FCMT080N65S3
ON Semiconductor- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 650V 38A 4TDFN
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 102
Can ship immediately
Pricing:
- 1$3.2802
Quote It
Technical Details
- Series:SuperFET® III
- Package:Tape & Reel (TR)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):650 V
- Current - Continuous Drain (Id) @ 25°C:38A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:80mOhm @ 19A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 880µA
- Gate Charge (Qg) (Max) @ Vgs:71 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:2765 pF @ 400 V
- FET Feature:-
- Power Dissipation (Max):260W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:4-TDFN (8x8)
- Package / Case:4-PowerTSFN
