IXTH500N04T2
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 500A TO247
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTH500N04T2 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$10.36433
- 30$10.36433
Quote It
Technical Details
- Series:TrenchT2™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:500A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:1.6mOhm @ 100A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:405 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:25000 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):1000W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-247 (IXTH)
- Package / Case:TO-247-3
