IXTH10N100D
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 1000V 10A TO247
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTH10N100D Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$11.23
- 30$11.23
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):1000 V
- Current - Continuous Drain (Id) @ 25°C:10A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:1.4Ohm @ 10A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:130 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:2500 pF @ 25 V
- FET Feature:Depletion Mode
- Power Dissipation (Max):400W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-247 (IXTH)
- Package / Case:TO-247-3
