IXFX64N50P
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 64A PLUS247-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXFX64N50P Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$14.31
- 30$12.02972
- 120$11.05416
- 510$9.42855
- 1,020$9.10342
Quote It
Technical Details
- Series:HiPerFET™, PolarHT™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:64A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:85mOhm @ 32A, 10V
- Vgs(th) (Max) @ Id:5.5V @ 8mA
- Gate Charge (Qg) (Max) @ Vgs:150 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:8700 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):830W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PLUS247™-3
- Package / Case:TO-247-3
