IXTR140P10T
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 100V 110A ISOPLUS247
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTR140P10T Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$16.05
- 30$16.05
Quote It
Technical Details
- Series:TrenchP™
- Package:Tube
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:110A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:13mOhm @ 70A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:400 nC @ 10 V
- Vgs (Max):±15V
- Input Capacitance (Ciss) (Max) @ Vds:31400 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):270W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:ISOPLUS247™
- Package / Case:TO-247-3
