IXTK32P60P
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 600V 32A TO264
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTK32P60P Datasheet
-
ECAD Model
- Share
In Stock: 2,120
Can ship immediately
Pricing:
- 1$18.04
- 25$15.17023
- 100$13.94
- 500$11.89
- 1,000$11.48
Quote It
Technical Details
- Series:PolarP™
- Package:Tube
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:32A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:350mOhm @ 16A, 10V
- Vgs(th) (Max) @ Id:4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:196 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:11100 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):890W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-264 (IXTK)
- Package / Case:TO-264-3, TO-264AA
