IXFN48N60P
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 40A SOT227B
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXFN48N60P Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$22.77
- 10$21.06225
- 30$19.3545
- 100$17.9883
- 250$16.50825
- 500$15.7113
Quote It
Technical Details
- Series:PolarHV™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:40A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:140mOhm @ 4A, 10V
- Vgs(th) (Max) @ Id:5.5V @ 8mA
- Gate Charge (Qg) (Max) @ Vgs:150 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:8860 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):625W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Chassis Mount
- Supplier Device Package:SOT-227B
- Package / Case:SOT-227-4, miniBLOC
