APT12067LFLLG

Technical Details

• Series:*
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):1200 V
• Current - Continuous Drain (Id) @ 25°C:18A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:670mOhm @ 9A, 10V
• Vgs(th) (Max) @ Id:5V @ 2.5mA

• Gate Charge (Qg) (Max) @ Vgs:150 nC @ 10 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:4420 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):-
• Operating Temperature:-
• Mounting Type:Through Hole
• Supplier Device Package:TO-264 [L]
• Package / Case:TO-264-3, TO-264AA
