IXTX17N120L
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 1200V 17A PLUS247-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXTX17N120L Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$34.105
- 30$34.105
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):1200 V
- Current - Continuous Drain (Id) @ 25°C:17A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):20V
- Rds On (Max) @ Id, Vgs:900mOhm @ 8.5A, 20V
- Vgs(th) (Max) @ Id:5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:155 nC @ 15 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:8300 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):700W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PLUS247™-3
- Package / Case:TO-247-3
