APTM100SK33T1G

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):1000 V
• Current - Continuous Drain (Id) @ 25°C:23A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:396mOhm @ 18A, 10V
• Vgs(th) (Max) @ Id:5V @ 2.5mA

• Gate Charge (Qg) (Max) @ Vgs:305 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:7868 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):390W (Tc)
• Operating Temperature:-40°C ~ 150°C (TJ)
• Mounting Type:Chassis Mount
• Supplier Device Package:SP1
• Package / Case:SP1
