NVJS3151PT1G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 12V 2.7A SC88
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$0.09
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Bulk
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):12 V
- Current - Continuous Drain (Id) @ 25°C:2.7A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:60mOhm @ 3.3A, 4.5V
- Vgs(th) (Max) @ Id:1.2V @ 50µA
- Gate Charge (Qg) (Max) @ Vgs:8.6 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:850 pF @ 12 V
- FET Feature:-
- Power Dissipation (Max):625mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SC-88/SC70-6/SOT-363
- Package / Case:6-TSSOP, SC-88, SOT-363
