IPU50R950CEAKMA2
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 4.3A TO251-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPU50R950CEAKMA2 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$0.18
- 1,500$0.18
Quote It
Technical Details
- Series:CoolMOS™ CE
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:4.3A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):13V
- Rds On (Max) @ Id, Vgs:950mOhm @ 1.2A, 13V
- Vgs(th) (Max) @ Id:3.5V @ 100µA
- Gate Charge (Qg) (Max) @ Vgs:10.5 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:231 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):53W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:PG-TO251-3
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
