IPD60R1K5CEATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 3.1A TO252-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPD60R1K5CEATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$0.64
- 2,500$0.21979
- 5,000$0.20561
- 12,500$0.19143
- 25,000$0.1815
Quote It
Technical Details
- Series:CoolMOS™ CE
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Discontinued at Digi-Key
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:3.1A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:1.5Ohm @ 1.1A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 90µA
- Gate Charge (Qg) (Max) @ Vgs:9.4 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:200 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):28W (Tc)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-252-3
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
