IPD65R250C6XTMA1
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 650V 16.1A TO252-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPD65R250C6XTMA1 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$1.08
- 2,500$1.08
Quote It
Technical Details
- Series:CoolMOS™
- Package:Bulk
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):650 V
- Current - Continuous Drain (Id) @ 25°C:16.1A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:250mOhm @ 4.4A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 400µA
- Gate Charge (Qg) (Max) @ Vgs:44 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:950 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):208.3W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TO252-3
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
