IRLZ24
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 17A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRLZ24 Datasheet
-
ECAD Model
- Share
In Stock: 172
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:17A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4V, 5V
- Rds On (Max) @ Id, Vgs:100mOhm @ 10A, 5V
- Vgs(th) (Max) @ Id:2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:18 nC @ 5 V
- Vgs (Max):±10V
- Input Capacitance (Ciss) (Max) @ Vds:870 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):60W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220AB
- Package / Case:TO-220-3
