IRF7809

Technical Details

• Series:HEXFET®
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:17.6A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V
• Rds On (Max) @ Id, Vgs:7.5mOhm @ 15A, 4.5V
• Vgs(th) (Max) @ Id:1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:86 nC @ 5 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:7300 pF @ 16 V
• FET Feature:-
• Power Dissipation (Max):3.5W (Ta)
• Operating Temperature:-
• Mounting Type:Surface Mount
• Supplier Device Package:8-SO
• Package / Case:8-SOIC (0.154", 3.90mm Width)
