IRLBA3803P

Technical Details

• Series:HEXFET®
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:179A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):-
• Rds On (Max) @ Id, Vgs:5mOhm @ 71A, 10V
• Vgs(th) (Max) @ Id:1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:140 nC @ 4.5 V
• Vgs (Max):-
• Input Capacitance (Ciss) (Max) @ Vds:5000 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):270W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:SUPER-220™ (TO-273AA)
• Package / Case:TO-273AA
