62-0063PBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 12V 15A 8SO
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet 62-0063PBF Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HEXFET®
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):12 V
- Current - Continuous Drain (Id) @ 25°C:15A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.8V, 4.5V
- Rds On (Max) @ Id, Vgs:8mOhm @ 15A, 4.5V
- Vgs(th) (Max) @ Id:1.9V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:40 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:2550 pF @ 6 V
- FET Feature:-
- Power Dissipation (Max):2.5W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SO
- Package / Case:8-SOIC (0.154", 3.90mm Width)
