FDP4020P

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:16A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:80mOhm @ 8A, 4.5V
• Vgs(th) (Max) @ Id:1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:13 nC @ 4.5 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:665 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):37.5W (Tc)
• Operating Temperature:-65°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220-3
• Package / Case:TO-220-3
