ZVN4306AVSTOA
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 1.1A E-LINE
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet ZVN4306AVSTOA Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:1.1A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):5V, 10V
- Rds On (Max) @ Id, Vgs:330mOhm @ 3A, 10V
- Vgs(th) (Max) @ Id:3V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:-
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:350 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):850mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:E-Line (TO-92 compatible)
- Package / Case:E-Line-3
