ZVNL120CSTOB

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):200 V
• Current - Continuous Drain (Id) @ 25°C:180mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):3V, 5V
• Rds On (Max) @ Id, Vgs:10Ohm @ 250mA, 5V
• Vgs(th) (Max) @ Id:1.5V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:85 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):700mW (Ta)
• Operating Temperature:-
• Mounting Type:Through Hole
• Supplier Device Package:E-Line (TO-92 compatible)
• Package / Case:E-Line-3
