ZXMN2A02X8TC
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 6.2A 8MSOP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet ZXMN2A02X8TC Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:6.2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:20mOhm @ 11A, 4.5V
- Vgs(th) (Max) @ Id:700mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:18.6 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1900 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):1.1W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-MSOP
- Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
