IRF6636TR1PBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 18A DIRECTFET
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRF6636TR1PBF Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HEXFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:18A (Ta), 81A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:4.5mOhm @ 18A, 10V
- Vgs(th) (Max) @ Id:2.45V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:27 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:2420 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):2.2W (Ta), 42W (Tc)
- Operating Temperature:-40°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DIRECTFET™ ST
- Package / Case:DirectFET™ Isometric ST
