BSS138W E6433

Technical Details

• Series:SIPMOS®
• Package:Tape & Reel (TR)
• Part Status:Discontinued at Digi-Key
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:280mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:3.5Ohm @ 220mA, 10V
• Vgs(th) (Max) @ Id:1.4V @ 26µA

• Gate Charge (Qg) (Max) @ Vgs:1.5 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:43 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):500mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-SOT323-3
• Package / Case:SC-70, SOT-323
