BTS113ANKSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 11.5A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet BTS113ANKSA1 Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TEMPFET®
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:11.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V
- Rds On (Max) @ Id, Vgs:170mOhm @ 5.8A, 4.5V
- Vgs(th) (Max) @ Id:2.5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:-
- Vgs (Max):±10V
- Input Capacitance (Ciss) (Max) @ Vds:560 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):40W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:P-TO220AB
- Package / Case:TO-220-3
