BSL211SPL6327HTSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 4.7A TSOP-6
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet BSL211SPL6327HTSA1 Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:4.7A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:67mOhm @ 4.7A, 4.5V
- Vgs(th) (Max) @ Id:1.2V @ 25µA
- Gate Charge (Qg) (Max) @ Vgs:12.4 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:654 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):2W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TSOP-6-6
- Package / Case:SOT-23-6 Thin, TSOT-23-6
