NTHD3101FT3G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 3.2A CHIPFET
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTHD3101FT3G Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:3.2A (Tj)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:80mOhm @ 3.2A, 4.5V
- Vgs(th) (Max) @ Id:1.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:7.4 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:680 pF @ 10 V
- FET Feature:Schottky Diode (Isolated)
- Power Dissipation (Max):1.1W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:ChipFET™
- Package / Case:8-SMD, Flat Lead
