IXFV110N10P

Technical Details

• Series:PolarHT™ HiPerFET™
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):100 V
• Current - Continuous Drain (Id) @ 25°C:110A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:15mOhm @ 500mA, 10V
• Vgs(th) (Max) @ Id:5V @ 4mA

• Gate Charge (Qg) (Max) @ Vgs:110 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:3550 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):480W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:PLUS220
• Package / Case:TO-220-3, Short Tab
