In Stock: 177

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:HEXFET®
  • Package:Tube
  • Part Status:Obsolete
  • FET Type:N-Channel
  • Technology:MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss):250 V
  • Current - Continuous Drain (Id) @ 25°C:14A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On):10V
  • Rds On (Max) @ Id, Vgs:260mOhm @ 8.4A, 10V
  • Vgs(th) (Max) @ Id:5V @ 250µA



  • Gate Charge (Qg) (Max) @ Vgs:35 nC @ 10 V
  • Vgs (Max):±30V
  • Input Capacitance (Ciss) (Max) @ Vds:810 pF @ 25 V
  • FET Feature:-
  • Power Dissipation (Max):144W (Tc)
  • Operating Temperature:-55°C ~ 175°C (TJ)
  • Mounting Type:Surface Mount
  • Supplier Device Package:D-Pak
  • Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63

Related Products


IRFR3418PBF

MOSFET N-CH 80V 70A DPAK

IRFR3418PBF Datasheet

Call for price


IRF7425PBF

MOSFET P-CH 20V 15A 8SO

IRF7425PBF Datasheet

Call for price


IRF7809PBF

MOSFET N-CH 28V 14.5A 8SO

Call for price


IRF7492PBF

MOSFET N-CH 200V 3.7A 8SO

IRF7492PBF Datasheet

Call for price


IRFU3710Z-701P

MOSFET N-CH 100V 42A IPAK

IRFU3710Z-701P Datasheet

Call for price


IRLU7833-701PBF

MOSFET N-CH 30V 140A IPAK

IRLU7833-701PBF Datasheet

Call for price


IRLU7843-701PBF
