STT2PF60L

Technical Details

• Series:STripFET™ II
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:2A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:250mOhm @ 1A, 10V
• Vgs(th) (Max) @ Id:1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:7 nC @ 10 V
• Vgs (Max):±15V
• Input Capacitance (Ciss) (Max) @ Vds:313 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):1.6W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-23-6
• Package / Case:SOT-23-6
