TK15A60U(STA4,Q,M)
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 15A TO220SIS
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet TK15A60U(STA4,Q,M) Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:DTMOSII
- Package:Tube
- Part Status:Last Time Buy
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:15A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:300mOhm @ 7.5A, 10V
- Vgs(th) (Max) @ Id:5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:17 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:950 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):40W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220SIS
- Package / Case:TO-220-3 Full Pack
