2N7002_NB9G002

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:115mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):5V, 10V
• Rds On (Max) @ Id, Vgs:7.5Ohm @ 500mA, 10V
• Vgs(th) (Max) @ Id:2.5V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:50 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):200mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-23 (TO-236AB)
• Package / Case:TO-236-3, SC-59, SOT-23-3
