TPCA8031-H(TE12L,Q

Technical Details

• Series:U-MOSV-H
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:24A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:11mOhm @ 12A, 10V
• Vgs(th) (Max) @ Id:2.5V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:21 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:2150 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):1.6W (Ta), 30W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:8-SOP Advance (5x5)
• Package / Case:8-PowerVDFN
